Pre Pressurized Accumulator Tank 1L Constant Pressure RV Accumulator Tank 1/2 MNPT Port for Boat Travel Trailer

Specification: Item Type: Accumulator Tank Size: Approx. 30 x 14.4cm / 11.8 x 5.7in Internal Volume: 1L (33.8FL.OZ) Inflation Pressure: 10PSI/0.7BAR Maximum Operating Pressure: 125PSI/8.6BAR Air Fill Valve: Standard Car Tire Valve Inlet Outlet Diameter: 1/2 Inch MNPT Product Use: Play the role of constant pressure, prevent the system pressure from rising and falling, so that the water is more gentle. Function: 1. In RV Use: It can effectively absorb the excess hot gas entering the water system pipeline due to the heater, and there will be no pop sound when the faucet is opened 2. When the RV Leaks: After the long term use of the RV, the pipeline connection may be loose, and the drip water leakage may occur, resulting in frequent start up of the pump. At this time, the pressure tank can effectively reduce the number of startup of the pump 3. During the Bath: The starts and stops frequently because of the uneven pipe and nozzle, and the pressure tank can effectively improve this situation Working Principle: 1. The pressure tank has pre charged pressure before leaving the factory. 2. When the is turned on, water enters the pressure tank. When the pressure tank is filled, the stops working. 3. When water is needed, the water in the pressure tank first enters the pipeline due to the action of air bladder pressure. The remains off until the pressure in the pressure tank is lower than the starting pressure of the pump, and the cycle repeats. Package List: 1 x Accumulator Tank 2 x Wing Nut Connector 1 x User Manual Notice: Please read the user manual carefully before use and adjust the air pressure in the tank below the pump switch pressure by 3psi (0.2bar).

• Easy Installation: The connection port adopts a threaded joint connection, and the wing nut connector is connected to one end of the accumulator tank. The hose is fixed by a clamp and connects the accumulator and the pump
• Constant Pressure: This tank has 1L large capacity, and is suitable for most pumps on the market, with a pressure range of 10psi-125psi, ensuring constant pressure, effectively solving pulsation problems in vehicle freshwater system
• Sealed and Secure: The inlet and outlet diameter is 1/2 inch MNPT, using standard car tire valve. The pressure tank provides a sealing structure to effectively prevent leakage or disconnection during use, improving security and reliability
• Product Usage: The accumulator tank provides constant pressure, reducing frequent start stop of the pump, making the water smoother, stabilizing and buffering, protecting the , and ensuring quiet and stable work
• Wide Application: Pre inflate the tank with a pressure of 10psi (0.7bar) before leaving the factory, compatible with RV and boat, food and drink filling, liquid conveying, and any other pressurization system, helping to reduce frequent pump starts
